Este ejemplo representa un oscilador de desplazamiento de fase realizado con un transistor JFET Canal-N, dos resistencias y una red de re-alimentación constituida por tres resistencias y tres condensadores idénticos. El condensador CS se utiliza para una configuración de drenaje común y CO permite desacoplar la salida de la red de re-alimentación. Esta red es destacada en un recuadro coloreado de fondo, que se genera usando la biblioteca de TiKZ "backgrounds"
Vo = tensión de salida.
VDD= polarización positiva en el terminal de drenaje.
Todos los componentes eléctricos y electrónicos carecen de valores o tipos.
Este esquema es una adaptación de la figura que se encuentra en la página http://www.circuitstoday.com/fet-applications.
